LGMR64  Incremental Optical Rotary Encoder

The LGMR64 series is a high-precision optical angle encoder designed for applications requiring compact size, robust performance, and exceptional accuracy. It features a micro-sized read head and supports multiple encoder disk options, including glass and stainless steel discs, ensuring flexibility for various industrial and automation needs.

Key Advantages & Benefits

  • High Resolution & Accuracy – Delivers precise angular measurement with low error.
  •  Compact & Lightweight – Micro read head enables integration in space-constrained systems.
  • Multiple Disk Options – Choose between glass (for high resolution) or stainless steel (for durability).
  • Robust Performance – Resistant to dust, vibrations, and EMI for reliable operation in harsh environments.
  • Easy Installation – Flexible mounting options simplify integration into rotary stages, robots, and servo systems.
  • Wide Application Range – Ideal for CNC machines, robotics, medical devices, and aerospace systems.

The LGMR64 optical ring encoder combines high performance, durability, and versatility, making it a top choice for precision motion control applications.

Technical Specifications

Description Parameter Remark
Working Voltage 5V ±5%
Operating Current Normal Operating <80ma:error alarm="">120mA 25℃ Room Temperature
Grating Pitch 64um
Travel speed Refer to disk selection manual(max 19200 RPM)
Resolution Refer to disk selection manual(min 0.16875 arc second)
Cable outlet method Direct outlet optional（DB9/DB15）
Sensor Material Aluminum
Cable Length Default 0.5 meters Customizable
Weight 23g(read head) 0.5 meters Read Head
Overall Dimensions 21*10*5MM
Operating Temperature -5 ... 70℃
Storage Temperature -20 ... 70℃

Electrical Connection

Cable Specification
Cable Type TPU high-flex cable, drag chain compatible, double shielding, twisted pair
Number of Wires 8-core
Outer Diameter 4.4 mm ±0.15 mm
Jacket Material TPU
Wire specs 0.08 mm2, 28 AWG, 0.38 Ω/m
Shielding Effectiveness 90%
Durability 40 million cycles at 35 mm bending radius
Weight nominal 34 g/m
Bending Radius(inner) Dynamic: 25 mm / Static: 10 mm
